Description
Fanvil X5U-R Dubai
The Fanvil X5U-R Dubai is a ruggedized IP phone designed for use in outdoor and harsh environments. It features a durable and robust design that can withstand extreme temperatures, dust, and water. The device is suitable for use in environments such as factories, warehouses, construction sites, and outdoor areas where standard IP phones may not be suitable.
The Fanvil X5U-R Dubai supports up to 16 SIP lines, which allows users to manage multiple phone numbers and call plans on a single device. The device features a 3.5-inch color screen that displays important information such as caller ID, call duration, and contacts. The screen is easy to navigate, and the icons are clear and intuitive.
The Fanvil X5U-R Dubai features advanced audio technologies such as noise reduction and echo cancellation, ensuring high-quality audio communication. It also has a full-duplex speakerphone and supports HD audio, making it easy for users to communicate clearly and effectively. The device has a built-in microphone and a 3.5mm audio jack, enabling users to connect external speakers or headphones.
The Fanvil X5U-R Dubai supports PoE (Power over Ethernet), which means that it can receive power and data over a single Ethernet cable. This feature eliminates the need for additional power cables, making installation easy and cost-effective. The device also supports VLAN (Virtual Local Area Network) and QoS (Quality of Service), ensuring that network traffic is prioritized and managed efficiently.
The Fanvil X5U-R Dubai has built-in Bluetooth and Wi-Fi connectivity, enabling users to connect to wireless networks and devices such as headsets, smartphones, and tablets. It also supports EHS (Electronic Hook Switch) and various types of headsets, including wireless, wired, and Bluetooth.
With a range of programmable keys, the Fanvil X5U-R Dubai is highly customizable and configurable. It supports various features, such as LDAP, XML phonebook, and multiple languages, making it suitable for use in various international settings. The device has 8 programmable keys and can support up to 30 DSS keys, allowing users to customize their phone according to their needs and preferences.
The Fanvil X5U-R Dubai is designed to withstand harsh environments. The device features a ruggedized design that can withstand extreme temperatures, dust, and water. It has an IP65 rating, which means that it is dust-tight and protected against water jets from any direction.
The Fanvil X5U-R Dubai is also designed with security in mind. It supports various security protocols, such as TLS, SRTP, HTTPS, and VLAN, ensuring that communications over the device are secure and protected against unauthorized access.
In conclusion, the Fanvil X5U-R Dubai is a ruggedized IP phone designed for use in harsh environments. Its durable and robust design, support for up to 16 SIP lines, advanced audio technologies, and built-in Bluetooth and Wi-Fi connectivity make it highly efficient and versatile. Its customizable features, PoE support, and advanced security features make it easy to use and highly adaptable to different settings. Whether for personal or professional use, the Fanvil X5U-R Dubai is an excellent choice for anyone looking for a reliable, high-performance IP phone that can withstand tough environment
Fanvil X5U-R Specifications
Generic
- 16 SIP Lines
HD voice
PoE enabled
2 LCDs (Main + DSS)
Intelligent DSS keys
Handset / hands-free / headset mode
Desktop stand / wall-mounted (need an additional wall hanging parts)
Optional external power supply
Phone Functions
Local phonebook (2000 entries)
Remote phonebook (XML/LDAP, 2000 entries)
Call logs (in/out/missed, 1000 entries)
Block/Allow List Call Filter
Screen saver
Voice message waiting indication (VMWI)
Programmable DSS/soft keys
Network time synchronization
Built-in bluetooth version 4.2 or above: support bluetooth headset/ bluetooth of mobile device
Support Wi-Fi Dongle (Via WF20)
Support Plantronics wireless headset (through Plantronics APD-80 EHS cable)
Support Jabra wireless headset (through Fanvil EHS20 EHS cable)
Support recording (through flash drive or server)
Action URL / Active URI
uaCSTA
Call Functions
Call out / answer / reject
Mute / unmute (microphone)
Call hold / resume
Call waiting
Intercom
Caller ID display
Speed dial
Anonymous call (hide caller ID)
Call forward (Always/Busy/No Answer)
Call transfer (Attended/Unattended)
Call parking/pick-up (depending on server)
Redial
Do-Not-Disturb
Auto-answering
Voice message (with server)
6-way conference
Hot line
Hot desking
Audio
HD voice microphone/speaker (handset/hands-free, 0 ~ 7KHz frequency response)
HAC handset
Wideband ADC/DAC 16KHz sampling
Narrowband codec: G.711a/u, G.729A/B, iLBC
Wideband codec: G.722, Opus
Full-duplex Acoustic Echo Canceller (AEC)
Voice Activity Detection (VAD) / Comfort Noise Generation (CNG)/ Background Noise Estimation (BNE) / Noise Reduction (NR) /Automatic Gain Control (AGC)
Packet Loss Concealment (PLC)
Dynamic adaptive jitter buffer
DTMF: In-band, Out-of-Band (RFC2833/ SIP INFO)
VQM voice quality monitoring
Network
Physical: 10/100/1000Mbps ethernet, dual bridged port for PC bypass
IP Mode:IPv4/IPv6/IPv4&IPv6
IP Configuration: Static IP / DHCP / PPPoE
Network Access Control: 802.1x
VPN: L2TP / OpenVPN
VLAN
LLDP
CDP
QoS
RTCP-XR (RFC3611), VQ-RTCPXR (RFC6035)
Protocols
SIP2.0 over UDP/TCP/TLS
RTP/RTCP/SRTP
STUN
DHCP
IPv6
LLDP
CDP
PPPoE
802.1x
L2TP
OpenVPN
SNTP
FTP/TFTP
HTTP/HTTPS
TR-069
AES128 & AES256
Physical Specifications
Main LCD: 3.5-inch (480×320) color screen
DSS key-mapping LCD: 2.4-inch (240×320) color screen
Keypad: 42 keys
HD handset (RJ9) x1
Standard RJ9 handset cord x1
1.5M CAT.5E ethernet cable x1
Back rack x1
Status indicator light x1 (Red)
RJ9 port x2: handset x1, headset x1
RJ45 port x2: network x1, PC x1 (bridged to network)
USB2.0 port x1: Standard A, connect with flash driver
DC port x1: Φ5.5×2.1x10mm
Safety keyhole x1
DC power input: DC5V / 2A
Working temperature: 0~45℃
Working humidity: 10~95%
Color: Red
Desktop stand (angles 1: 45 degree): 214×188.6×181.1 mm
Desktop stand (angles 2: 50 degree): 214×180.5×190.1 mm
Wall-mounted: 214×119.4×219.1 mm
Gift box dimensions: 315x228x84 mm
Outer CTN dimensions: 476x440x335 mm (10 PCS)
