| Imaging Device |
1/2.8″ 5MP CMOS |
| Resolution |
5MP mode : 2592×1944, 1920×1080, 1280×960, 1280×720, 800×600, 800×448, 720×576, 720×480, 640×480, 640×360, 320×240 4MP mode : 2560×1440, 1920×1080, 1280×960, 1280×720, 800×600, 800×448, 720×576, 720×480, 640×480, 640×360, 320×240 |
| Max. Framerate |
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz) MJPEG: Max. 15fps/12fps(60Hz/50Hz) |
| NETD |
None |
| Pixel Size |
None |
| Min. Illumination |
Color: 0.15Lux(F1.6, 1/30sec) BW: 0Lux(IR LED on) |
| Video Out |
CVBS: 1.0 Vp-p / 75Ω composite, 720×480(N), 720×576(P) for installation |
| Video Transmission Distance |
None |
| Lens |
|
| Focal Length (Zoom Ratio) |
4.0mm fixed focal |
| Max. Aperture Ratio |
F1.6 |
| Angular Field of View |
H: 79.8°/ V: 58.1°/ D: 105.9° |
| Pan / Tilt / Rotate |
|
| Pan / Tilt / Rotate Range |
None |
| Pan Range |
None |
| Pan Speed |
None |
| Tilt Range |
None |
| Tilt Speed |
None |
| Rotate Range |
None |
| Sequence |
None |
| Preset Accuracy |
None |
| Operational |
|
| Camera Title |
Displayed up to 85 characters |
| Direction Indicator |
None |
| Day & Night |
Auto(ICR) |
| Backlight Compensation |
BLC, WDR, SSDR |
| Wide Dynamic Range |
120dB |
| Digital Noise Reduction |
SSNR |
| Digital Image Stabilization |
None |
| Defog |
None |
| Motion Detection |
4ea, polygonal zones |
| Privacy Masking |
6ea, rectangular zones |
| Gain Control |
Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
| LDC |
Support |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (1/5~1/12,000sec) |
| Digital PTZ |
None |
| Video Rotation |
Flip, Mirror, Hallway view(90˚/270˚) |
| Analytics |
Defocus detection, Directional detection, Motion detection, Enter/Exit, Tampering, Virtual line |
| Business Intelligence |
None |
| Serial Interface |
None |
| Alarm I/O |
Input 1ea / Output 1ea |
| Alarm Triggers |
Analytics, Network disconnect, Alarm input |
| Alarm Events |
File upload via FTP and e-mail Notification via e-mail SD/SDHC/SDXC or NAS recording at event triggers Alarm output |
| Audio In |
None |
| Audio Out |
None |
| IR Viewable Length |
25m(82.02ft) |
| IR Illuminator (Optional) |
None |
| Water Removal |
None |
| Auto Tracking |
None |
| Coaxial Protocol |
None |
| Color Palettes |
None |
| Radiometry |
|
| Temperature detect range |
None |
| Temperature accuracy |
None |
| Temperature detection |
None |
| Additional |
None |
| Network |
|
| Ethernet |
RJ-45(10/100BASE-T) |
| Video Compression |
H.265/H.264: Main/High, MJPEG |
| Audio Compression |
None |
| Smart Codec |
WiseStreamⅡ |
| Video Quality Adjustment |
H.264/H.265: Target bitrate level control MJPEG: Quality level control |
| Bitrate Control |
H.264/H.265: CBR or VBR MJPEG: VBR |
| Streaming |
Unicast(6 users) / Multicast Multiple streaming(Up to 3 profiles) |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP |
| Security |
HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP) |
| Application Programming Interface |
ONVIF Profile S/G/T SUNAPI(HTTP API) Wisenet open platform |
| General |
|
| Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch |
| Web Viewer |
None |
| Edge Storage |
Micro SD/SDHC/SDXC 1slot 128GB |
| Memory |
512MB RAM, 256MB Flash |
| Environmental & Electrical |
|
| Operating Temperature / Humidity |
-30°C ~ +55°C(-22°F ~ +131°F) / Less than 90% RH * Start up should be done at above -20°C |
| Storage Temperature / Humidity |
-30°C ~ +60°C(-22°F ~ +140°F) / Less than 90% RH |
| Certification |
IP66, IK10 |
| Input Voltage |
PoE(IEEE802.3af, Class3) |
| Power Consumption |
PoE: Max 7.50W, typical 6.10W |
| Mechanical |
|
| Color / Material |
Dark grey / Aluminum |
| RAL Code |
None |
| Product dimensions / weight |
Ø70.0×246.0mm(Ø4.33×3.39″), 680g(1.50 lb) |
| Conduit hole |
None |
| Hanging mount(Dome) |
None |
| Skin cover(Dome) |
None |
| Weather cap(Dome) |
None |
| Power module |
None |
| Backbox |
SBO-100B1 |
| DORI (EN62676-4 standard) |
|
| Detect (25PPM/ 8PPF) |
62.0m(203.39ft) |
| Observe (63PPM/ 19PPF) |
24.8m(81.36ft) |
| Recognize (125PPM/ 38PPF) |
12.4m(40.68ft) |
| Identify (250PPM/ 76PPF) |
6.2m(20.34ft) |
