Description
Hanwha QNO7020R CCTV Camera
The Hanwha QNO7020R CCTV Camera is a state-of-the-art security solution designed to deliver exceptional outdoor surveillance. With its 4-megapixel resolution (2688×1520), this high-definition camera captures ultra-clear video footage, ensuring that critical details are never missed. Its rugged construction is built to endure extreme weather conditions, featuring an IP66-rated weatherproof housing that provides resistance against dust, heavy rain, intense heat, and freezing temperatures.
Advanced Features for Superior Security
Equipped with infrared (IR) night vision up to 30 meters, the Hanwha QNO7020R ensures round-the-clock surveillance, even in complete darkness. Its 120dB Wide Dynamic Range (WDR) enhances image clarity by balancing exposure in challenging lighting conditions, preventing overexposure in bright areas and improving visibility in darker scenes. The 3.6mm fixed lens offers a wide field of view, making it an ideal solution for monitoring expansive outdoor spaces.
This IP66-rated security camera supports H.265, H.264, and MJPEG compression formats, optimizing bandwidth usage while maintaining high video quality. Additionally, its intelligent video analytics, including motion detection, tampering detection, and defocus detection, provide proactive security monitoring, alerting users to any suspicious activity.
Ideal for Residential, Commercial, and Industrial Security
The Hanwha QNO7020R CCTV camera is highly versatile and well-suited for a variety of security applications:
- Home Security: Helps homeowners monitor their property, ensuring safety and peace of mind.
- Commercial Surveillance: Ideal for securing parking lots, warehouses, retail stores, and office buildings, reducing the risk of theft and unauthorized access.
- Industrial & Construction Sites: Designed to withstand harsh conditions, making it perfect for monitoring industrial facilities and large-scale construction projects.
- Public Safety: Enhances security in parks, campuses, government buildings, and public event spaces, providing continuous monitoring in high-traffic areas.
Seamless Integration with Security Systems
The Hanwha QNO7020R is ONVIF-compliant, ensuring seamless integration with most existing security management systems. It is also compatible with Hanwha’s proprietary security software, offering a centralized platform for remote monitoring, management, and real-time alerts. With Power over Ethernet (PoE) and 12V DC power supply options, installation is flexible and convenient, making it an excellent choice for both new and existing security infrastructures.
Why Choose the Hanwha QNO7020R?
For businesses, homeowners, and security professionals looking for a high-performance outdoor surveillance camera, the Hanwha QNO7020R is a top-tier choice. Its durable design, high-resolution imaging, night vision capability, and smart analytics make it one of the most reliable and efficient security cameras on the market. Whether you need to monitor a residential property, a commercial facility, or an industrial site, this camera delivers uncompromised performance and superior protection in any environment.
By investing in the Hanwha QNO7020R, you’re ensuring robust, 24/7 surveillance with cutting-edge technology designed for maximum security and peace of mind.
Specifications:
| Video | |
| Imaging Device | 1/3″ 4MP CMOS |
| Effective Pixels | 2688(H)x1520(V) |
| NETD | None |
| Pixel Size | None |
| Min. Illumination | Color: 0.4Lux(F2.2, 1/30sec) BW: 0Lux(IR LED on) |
| Video Out | None |
| Lens | |
| Focal Length (Zoom Ratio) | 3.6mm fixed focal |
| Max. Aperture Ratio | F2.2 |
| Angular Field of View | H: 81.0° / V: 45.0° / D: 95.0° |
| Min. Object Distance | None |
| Focus Control | Fixed |
| Lens Type | None |
| Mount Type | None |
| Optional Lens | None |
| Pan / Tilt / Rotate | |
| Pan / Tilt / Rotate Range | None |
| Pan Range | None |
| Pan Speed | None |
| Tilt Range | None |
| Tilt Speed | None |
| Rotate Range | None |
| Sequence | None |
| Preset Accuracy | None |
| Azimuth | None |
| Auto Tracking | None |
| Operational | |
| IR Viewable Length | 25m(82.02ft) |
| Camera Title | Displayed up to 20 characters per line(Max.5 lines) |
| Day & Night | Auto(ICR) |
| Backlight Compensation | BLC, WDR, SSDR |
| Wide Dynamic Range | 120dB |
| Digital Noise Reduction | SSNR |
| Digital Image Stabilization | None |
| Defog | None |
| Motion Detection | 4ea, polygonal zones |
| Privacy Masking | 6ea, rectangular zones |
| Gain Control | Low / Middle / High |
| White Balance | ATW / AWC / Manual / Indoor / Outdoor |
| LDC | Support |
| Electronic Shutter Speed | Minimum / Maximum / Anti flicker |
| Digital PTZ | None |
| Video Rotation | Flip, Mirror, Hallway view(90˚/270˚) |
| Analytics | Defocus detection, Motion detection, Tampering |
| Business Intelligence | None |
| Serial Interface | None |
| Alarm I/O | Input 1ea / Output 1ea |
| Alarm Triggers | Analytics, Network disconnect, Alarm input |
| Alarm Events | File upload via FTP and e-mail Notification via e-mail SD/SDHC/SDXC or NAS recording at event triggers Alarm output |
| Audio In | Line in Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm |
| Audio Out | None |
| IR Illuminator (Optional) | None |
| Wiper | None |
| Coaxial Protocol | None |
| Video Transmission Distance | None |
| Radiometry | |
| Temperature detect range | None |
| Temperature accuracy | None |
| Temperature detection | None |
| Additional | None |
| Network | |
| Ethernet | RJ-45(10/100BASE-T) |
| Video Compression | H.265/H.264, MJPEG |
| Resolution | 2592×1520, 2560×1440, 2304×1296, 1920×1080, 1280×1024, 1280×960, 1280×720, 1024×768, 800×600, 800×448, 720×576, 720×480, 640×480, 640×360, 320×240 |
| Max. Framerate | H.265/H.264: Max. 20fps@4MP, Max. 30fps/25fps(60Hz/50Hz) 2MP, all resolution, MJPEG: Max 15fps/12fps(60Hz/50Hz) |
| Smart Codec | WiseStreamⅠ |
| Video Quality Adjustment | H.264/H.265: Target bitrate level control MJPEG: Quality Level control |
| Bitrate Control | H.264/H.265: CBR or VBR MJPEG: VBR |
| Streaming | Unicast(6 users) / Multicast Multiple streaming(Up to 3 profiles) |
| Audio Compression | G.711 u-law /G.726 Selectable G.726(ADPCM) 8KHz, G.711 8KHz G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps |
| Protocol | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
| Security | HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP) |
| Edge Storage | Micro SD/SDHC/SDXC 1slot 128GB |
| Application Programming Interface | ONVIF Profile S/G SUNAPI(HTTP API) |
| Webpage Language | English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
| Web Viewer | Supported OS: Windows 7, 8.1, 10, Mac OS X 10.10, 10.11, 10.12 Recommended Browser: Google Chrome Supported Browser: MS Explorer11, MS Edge, Mozilla Firefox(Windows 64bit only), Apple Safari(Mac OS X only) |
| Memory | 512MB RAM, 256MB Flash |
| Environmental | |
| Operating Temperature / Humidity | -30°C ~ +55°C(-22°F ~ +131°F) / Less than 90% RH * Start up should be done at above -20°C |
| Storage Temperature / Humidity | -30°C ~ +60°C(-22°F ~ +140°F) / Less than 90% RH |
| Certification | IP66, IK10 |
| Electrical | |
| Input Voltage | PoE(IEEE802.3af, Class3), 12VDC |
| Power Consumption | PoE: Max 7.00W 12VDC: Max 6.00W |
| Mechanical | |
| Color / Material | Dark grey / Aluminum |
| RAL Code | |
| Product dimensions / weight | Ø70.0×246.0mm(Ø2.76×9.69″), 730g(1.61 lb) |
